2012 OKUMA LB-3000EX-II-MYW 800 SPACE TURN
Have one to sell?
ConditionUsed
1 available
Okuma LB3000EXII-MYW/800 with OSPO P300L Control, LNS Barfeed, Parts Catcher, Sub-Spindle, Y-Axis, Live Tooling, and More
SWING OVER BED.....................22.83"
SWING OVER CROSS SLIDE.............18.5"
MAX CUTTING DIAMETER...............13.39"
MAX CUTTING LENGTH.................31.5"
DISTANCE BETWEEN CENTERS...........42.72"
X-AXIS TRAVEL......................10.24"
Y-AXIS TRAVEL......................4.53" (+2.76" / -1.77")
Z-AXIS TRAVEL......................39.76"
C-AXIS INDEX.......................FULL C-AXIS
BAR CAPACITY.......................3.18"
SPINDLE BORE.......................3.59"
SPINDLE NOSE.......................A2-8
SPINDLE MOTOR......................40 HP
SPINDLE SPEED......................4,200 RPM
SUB SPINDLE CHUCK SIZE (INCHES)....6"
SUB SPINDLE BORE...................2.44"
SUB SPINDLE MOTOR..................15 HP
SUB SPINDLE SPEED..................6,000 RPM
TURRET CAPACITY....................12
LIVE MILLING.......................6,000 RPM
Machine Dimensions (L x W x H).....137" x 82" x 98"
Machine Weight.....................14,520 Lbs
OSP P300L CNC Control
Collet Chucks on Main and Sub Spindle
Tool Presetter
Parts Catcher
Live Tooling
Sub-Spindle
Y-Axis
LNS Servo Bar Feed
Chip Conveyor
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
Okuma LB3000EXII-MYW/800 with OSPO P300L Control, LNS Barfeed, Parts Catcher, Sub-Spindle, Y-Axis, Live Tooling, and More
Imperial
| Swing | 22.83" |
| Power | 30 hp |
| Max RPM | 6,000 RPM |
| Turning Dia | 13.39" |
| Sub Spindle | Yes |
| Control | CNC (OSP P300L) |
| Dimensions | 137" x 82" x 98" |
| Weight | 14,520 LBS |
SWING OVER BED.....................22.83"
SWING OVER CROSS SLIDE.............18.5"
MAX CUTTING DIAMETER...............13.39"
MAX CUTTING LENGTH.................31.5"
DISTANCE BETWEEN CENTERS...........42.72"
X-AXIS TRAVEL......................10.24"
Y-AXIS TRAVEL......................4.53" (+2.76" / -1.77")
Z-AXIS TRAVEL......................39.76"
C-AXIS INDEX.......................FULL C-AXIS
BAR CAPACITY.......................3.18"
SPINDLE BORE.......................3.59"
SPINDLE NOSE.......................A2-8
SPINDLE MOTOR......................40 HP
SPINDLE SPEED......................4,200 RPM
SUB SPINDLE CHUCK SIZE (INCHES)....6"
SUB SPINDLE BORE...................2.44"
SUB SPINDLE MOTOR..................15 HP
SUB SPINDLE SPEED..................6,000 RPM
TURRET CAPACITY....................12
LIVE MILLING.......................6,000 RPM
Machine Dimensions (L x W x H).....137" x 82" x 98"
Machine Weight.....................14,520 Lbs
OSP P300L CNC Control
Collet Chucks on Main and Sub Spindle
Tool Presetter
Parts Catcher
Live Tooling
Sub-Spindle
Y-Axis
LNS Servo Bar Feed
Chip Conveyor
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
