Miyano BNJ-42S Dual Spindle CNC Turning Center with Live Tooling

Work Length.....................3.9"
Turning Diameter (Main).........5"
Turning Diameter (Sub)..........4"
Bar Capacity....................1.65"
Spindle Speed...................5,000 RPM
Main Motor......................15 HP
Sub Spindle Motor...............7.5 HP
Turret Capacity.................12
Turret Index Time...............0.2 seconds
X1-Slide Travel.................6.10"
Z1-Slide Travel.................9.84"
Back Turret Capacity............6
Turret Index Time...............0.2 seconds
X2-Slide Travel.................2.75"
Z2-Slide Travel.................20.3"
Machine Dimensions..............106" x 59" x 68"
Machine Weight..................10,140 lbs
