Mazak HCN-8800-II
Have one to sell?
ConditionUsed
1 available
2009 Mazak HCN-8800-II with Matrix Control, Full 4th Axis, 60 ATC, 8,000 RPM, CAT-50 Hi-Torque Spindle.
Pallet Size......................31.5" x 31.5" (2)
Pallet Load Capacity.............4,850 LBS
Spindle Center to Table Top......1.97" - 56.1"
Spindle Nose to Table Center.....3.94" - 51.18"
X-Axis Travel....................55.12"
Y-Axis Travel....................47.24"
Z-Axis Travel....................52.17"
Pallet Index.....................0.001
Main Motor.......................50 HP
Spindle Taper....................CAT-50
Spindle Speed....................8,000 RPM Hi-Torque
Rapid Traverse Rates.............2,047 IPM
Number of Tools..................60 ATC
Max Tool Diameter (Empty Adj.)...10.2"
Max Tool Weight..................59.4 LBS
Machine Weight...................67,000 LBS
Mazak Matrix CNC Control
Manual Pulse Generator
Niagara Coolant
Spindle Chiller Unit
Tool Magazine Capacity 60 ATC
Absolute Positioning System
Auto Tool Length Measurement
Tool Breakage Detection
GOO Slope Constant
N/C Rotary Table (360,000 Positions)
Spindle Point Orient
Synchronized Tapping
USB - I/F 2 Ports
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
