Acer EMC-35100 Vertical Machining Center

Have one to sell?
602-516-4267
sales@tighttolerancemachinery.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
Vertical Machining Centers
Manufacturer:
ACER
Model:
EMC 35100
Year:
2008
Stock #:
197972502026467
Status:
For Sale

Description

2008 Acer EMC-35100 Vertical Machining Center with Anilam CNC Control, 8,000 RPM, CAT-40 Spindle, 24 ATC.

X98.4"2,499.4 mm
Y33"838.2 mm
Z25.5"647.7 mm
Power18 hp13.4 kW
RPM8,000 RPM8,000 RPM
# ATC2424
TaperCAT#40/BT#40CAT#40/BT#40
Table-W30"762 mm
Table-L112"2,844.8 mm
# Axis33
Dimensions170" x 126" x 115"170" x 126" x 115"
Weight18,700 LBS18,700 LBS

Table Size..................112" x 30"
X-Axis Travel...............98.4"
Y-Axis Travel...............33"
Z-Axis Travel...............25.5"
Spindle Motor...............18 HP
Spindle Taper...............CAT-40
Spindle Speed...............8,000 RPM
Number of Tools.............24 ATC
Machine Dimensions..........170" x 126" x 115"
Machine Weight..............18,700 LBS

ANILAM 6000M control
Box Ways on Y & Z Axis

**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
