Enshu JE50S Horizontal Machining Center

Pallet Size / Number of Pallets.........15.7" x 15.7" / 2
Table Load Capacity.....................880 lbs
X-Axis Travel...........................19.7"
Y-Axis Travel...........................19.7"
Z-Axis Travel...........................19.7"
Table Indexing..........................1 Degree Index
Tool Magazine Capacity..................40 Position ATC
Dist. From Spindle Center to Table Top..9.85" to 29.55"
Spindle Motor 30 Min. / Cont............20 HP
Spindle Nose............................CAT 40
Spindle Speed...........................12,000 RPM
Max. Tool Diameter......................2.95"
Rapid Traverse..........................2,362 IPM
Machine Dimensions LxWxH................151" x 78" x 110"
Machine Weight..........................15,000 lbs
