Fanuc Robocut C600iB Wire EDM

Max Workpiece Dimensions.................41.33" x 32.28" x 11.81"
Max Workpiece Weight.....................2200 LBS
X-Axis...................................23.62"
Y-Axis...................................15.75"
Z-Axis...................................12.20"
UV-Axis Travel...........................7.87" x 7.87"
Max Taper Angle [ ° / mm]................± 30°/150
Wire Diameter............................0.0039" – 0.0118"
Max Wire Weight..........................35 LBS
Machine Footprint........................98" x 106"
Machine Weight...........................6,650 LBS
