Sunnen CV-616E Cylinder King Honing Machine

Diameter Range............................3/4" – 8"
Length Range Depending on Diameter........Up to 18"
Spindle Speeds (4 speeds).................125, 170, 230, 310 RPM
Stroking Rate.............................41, 57, 80 SPM
Stroking Length...........................0 – 9"
Main Spindle Motor........................2 HP
Honing Oil Pump Motor.....................1/2 HP
Oil Cooler Motor..........................1/2 HP
Electrics.................................230/460V/3Ph/60Hz (currently configured for 460V)
Machine Dimesions – Actual................67" L x 70" W x 75" H
Approximate Weight........................2,400 Lbs.
