Haas SL-30TB CNC Lathe

Max Swing......................30"
Swing over Cross Slide.........14.5"
Max Turning Diameter...........16"
Max Turning Length.............34"
Distance between Centers.......39"
X-Axis Travel..................11.3"
Z-Axis Travel..................34"
Spindle Motor..................40 HP
Spindle Nose...................A2-8
Spindle Bore...................4.62"
Max Bar Capacity...............4"
Spindle Speed..................2,400 RPM
Rapids.........................710 IPM
Number of Tools................12 Station Turret
Tailstock Taper................MT4
Tailstock Travel...............33.5"
Approximate Dimensions.........165" x 77" x 74"
Approximate Weight.............17,500 LBS
