QuickTECH i-42 Twin Spindle Mill/Turn Center

Max Bar Working Capacity...............1.65"
Max Turning Length.....................9.8"
Spindle Speed Range (std.).............6,000 RPM
Spindle Motor..........................15 HP
Spindle Nose...........................A2-5
C-Axis Increment.......................0.001°
Sub-Spindle Capacity
Max Bar Working Capacity...............1.65"
Max Turning Length.....................3.94"
Spindle Speed Range....................6,000 RPM
Spindle Motor..........................7.5 HP Integral Motor
C-Axis Increment.......................0.001°
Travel and Feed
Rapid Traverse Rate....................1,181 IPM
Tooling System (Main)
Tooling Type...........................Gang Tool / Servo Y-Axis / KM-25 Quick Change
Number of Turning Tools................6 O.D. (5 + 1 cut-off) & 5 I.D.
Square Shank Size......................0.75" (20mm)
Boring Bar Capacity....................0.75" (ED-20)
B-Axis.................................360°
B-Axis Index Time......................0.3 Seconds 90° / .6 Seconds 360°
Number of Live Tools...................12
Live Tool Spindle Motor................2 HP
Live Tool Spindle Speed................4,000 RPM
Live Tool Shank........................ER-20 Collet
Tooling System (Sub)
Tooling Type...........................Gang Tool / Servo Y-Axis / KM-25 Quick Change
Number of Turning Tools................5 O.D. & 9 I.D.
Square Shank Size......................0.75" (20mm)
Boring Bar Capacity....................0.75" (ER-20)
B-Axis.................................360°
B-Axis Index Time......................0.3 Seconds 90° / 6 Seconds 360°
Number of Live Tools...................12
Live Tool Spindle Motor................2 HP
Live Tool Spindle Speed................4,000
Live Tool Shank........................ER-20 Collet
Machine Dimensions with Chip Conveyor..138" x 75" x 75"
Machine Weight.........................8,840 LBS
