Ganesh Cyclone 32CS CNC Turning Center

Main Spindle:
Main Spindle Motor.....................10 HP
Main Spindle Speed.....................6000 RPM
Main Bar stock Diameter................1.25"
X-Axis Travel..........................7.28"
Y-Axis Travel..........................19.29"
Z-Axis Travel..........................6.50"
C-Axis Travel..........................0.001 Degree
Rapid Travel Speed.....................1180 IPM
Min. Input Unit........................0.00005"
OD Turning Tool Positions..............6 OD Tools (1/2" or 12mm)
ID Turning Tool Positions..............5 ID Tools
OD Turning Tool Size...................1/2" or 12mm
ID Turning Tool Bore Size..............25mm
Spindle Center Height..................38"
Live Tools:
Cross Slide............................4 Cross Slide Live Tools
Front Slide............................3 Front Slide Live Tools
Live Tool Collet Size..................ER-20 Collet, 1/2" (13mm) Tool Shank
Live Tooling Speed.....................4,000 RPM
Sub-Spindle:
Sub Spindle Motor......................5/7.5 HP
Sub Spindle Max. Bar stock Diameter....1.25"
Sub Spindle Speed......................6000 RPM
Sub Spindle X-Axis.....................11.53"
Sub Spindle Z-Axis.....................11.61"
Sub Spindle C-Axis.....................0.001 Degree
Min. Input Unit........................0.00005"
ID Turning Tool Bore Size..............25mm
Coolant Tank...........................57" x 42" x 15" 150 LBS
Machine................................99" x 63" x 82" 8,360 LBS
