Okamoto ACC-12.24 DXNC

Table Capacity...................................12" x 24"
Max Distance under 12" Wheel to Table Surface....13.6"
Table Load Capacity..............................925 LBS
T-Slots..........................................0.7" x 3
Maximum Table Travel.............................30"
Table Feed Rate..................................3-82 ft/min
Feed Per Handwheel Revolution....................1.85"
Maximum Saddle Travel............................13.3"
Intermittent Traverse Feed.......................0.02 - 080 IPM
Grinding Feed....................................0.001 - 40 IPM
Rapid Feed.......................................40 IPM
Jog Feed.........................................40 IPM
Manual Pulse Generator...........................0.00001", 0.0001", 0.001"
Grinding Wheel Size..............................12" x 1.5" x 5"
Speed............................................500 - 1,800 RPM
Grinding Wheel Sindle Motor......................7.5 HP
Crossfeed AC Servo Motor.........................0.7 HP
Vertical Feed AC Servo Motor.....................0.7 HP
Hydraulic Pump Motor.............................2 HP
Floor Space......................................107" x 79" x 95"
Weight...........................................6,175 LBS
