2016 Salvagnini B3-220/4250 CNC Press Brake
Have one to sell?
ConditionUsed
1 available
2016 Salvagnini B3-220/4250 242 Ton x 14' CNC Press Brake - MVM Adjustable Bottom Die, ATA, CNC Crowning, 5-Axis Back Gauge, AMS, Wila Clamping.
Tonnage........................242 Tons
Max Bending Length.............167"
Distance Between Side Frames...145.5"
Open Height....................27.6"
Stroke.........................17.7"
Throat Depth...................20.47"
Max Speed......................519 IPM
Bending Speed..................42 IPM
Main Motor.....................35 HP
Dimensions.....................210" x 82" x 146"
Approximate Weight.............52,600 LBS
MVM Adjustable Bottom Die – up to 2" Opening – Automatically Adapts the Opening of the Vee Opening Based on the Program
ATA – Automatically Adjusts the Upper Bending Tool Length
CNC Crowning
5 Axis Back Gauge
AMS – Angle Measurement System
Oil Cooler
Lazer Safe Safety Lights
12′ Length of 8" Tall ATA Gooseneck Punch
Wila Hydraulic Top Clamping
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
