Cincinnati Cinturn 18U-100
Have one to sell?
ConditionUsed
1 available
Cincinnati Cinturn 18U-100 - Rebuilt and in Excellent Condition. Fanuc 32i Model A Control, 18" Chuck, 100" Centers, Two Turrets, SMW Autoblok Steadyrest, Tailstock.
SWING OVER THE SLANT BED............ 28"
SWING OVER THE CARRIAGE............. 18.25"
DISTANCE BETWEEN CENTERS.............100"
X-AXIS TRAVEL........................18"
Z-AXIS TRAVEL........................100"
SPINDLE MOTOR........................50 HP
SPINDLE BORE.........................4.5"
SPINDLE NOSE.........................A1-11
SPINDLE SPEED........................1,500 RPM
ELECTRICS............................480V/3PH/60HZ
TURRETS (2)..........................6 ID/6 OD
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
Fanuc 32iA Control
18" Rohm 3-Jaw Chuck
(2) 6-Station Turrets
SMW Autoblok Steadyrest
Tailstock
Chip Conveyor
**BARDONS & OLIVER REBUILD**
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
Cincinnati Cinturn 18U-100 - Rebuilt and in Excellent Condition. Fanuc 32i Model A Control, 18" Chuck, 100" Centers, Two Turrets, SMW Autoblok Steadyrest, Tailstock.
Imperial
| Swing | 28" |
| Machining Length | 100" |
| Chuck Size | 18" |
| Bar Capacity | 4" |
| Power | 50 hp |
| Max RPM | 1,500 RPM |
| Tailstock | Yes |
| Live Tooling | No |
| Sub Spindle | No |
| Control | CNC (Fanuc 32iA) |
SWING OVER THE SLANT BED............ 28"
SWING OVER THE CARRIAGE............. 18.25"
DISTANCE BETWEEN CENTERS.............100"
X-AXIS TRAVEL........................18"
Z-AXIS TRAVEL........................100"
SPINDLE MOTOR........................50 HP
SPINDLE BORE.........................4.5"
SPINDLE NOSE.........................A1-11
SPINDLE SPEED........................1,500 RPM
ELECTRICS............................480V/3PH/60HZ
TURRETS (2)..........................6 ID/6 OD
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
Fanuc 32iA Control
18" Rohm 3-Jaw Chuck
(2) 6-Station Turrets
SMW Autoblok Steadyrest
Tailstock
Chip Conveyor
**BARDONS & OLIVER REBUILD**
**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
