Tauring Alpha 200 CNC Angle Bending Roll

DESCRIPTION:
Alpha200CNCi - "CNC" stands for "computerized, numerical control", "i" for "interpolation" and "PLUS" for "plus value".
It is the evolution of an already astonishing product that today is even more amazing.
The CNCi is an advanced numerical control Windows based able to manage two or more interpolated axes with unsurpassed
progression and accuracy. The 15" touch screen can activate macro-instructions and commands by simply touching the
icons presented on the screen. One of CNCi strength points is represented by its simple and intuitive software, that allows
programming any types of geometrical shape - regular and irregular - by simply drawing it on the screen or importing it
from a "dxf" file. The shape can then be modified by simply acting on its segments so to make them longer or shorter or
clicking on the arrow to enlarge or reduce the bending curves; all tasks are recognized by the "bending program"

SPECIFICATIONS:
Round Tube.......................10.75" x 0.5" / Min. Radius: 87"
Square Tube......................10" x 10" x .40" / Min. Radius: 80"
Flat Bar (Hard Way)..............10" x 2.3 / Min. Radius: 32"
Angle (Leg Out)..................7.8" x 7.8" x 0.78" / Min. Radius: 78"
H Beam...........................IPE 330 / Min. Radius: 75" (MINIMUM RADII SHOWN MAY REQUIRE MULTI PASS)
Driven Rolls.....................3
Shaft Diameter...................490 mm
Standard Shaft Working Length....15.75"
Shaft Revolutions Per Minute.....7.1 RPM
Main Motor Motor.................24.1 HP
Dimensions / Weight..............41"W x 61"L x 74"H / Machine Weight - 22,046 lbs.
Current Electrics................480V /3PH /60Hz
