Odell Mobile Cleaning Station 1735

Overall dimensions approximately.......42.5" wide x 35" deep x 80" high
Weight is approximately................562 pounds
Power requirements.....................Two separate 20A, 115V, 60Hz. GFI circuits
Air requirements.......................Dry compressed Air approximately 10cfm @ 50psi
Water requirements.....................Standard cold tap water with 3/4" hose connection
Drain requirements.....................3/4" garden hose, gravity fed.
Construction...........................11, 14 and 16 gauge cold rolled steel with powder-coat finish

FEATURES:
The largest, unobstructed mobile cleaning chamber in the industry
Opening measures 37" wide x 33.5" high, with a total chamber
area of 32.6 cu.ft. (easily holds 35" T.V.)

Slide out turntable, with adjustable stops, helps reduce back strain from
repetitive loading and unloading of equipment into chamber.
(Fully extended turntable has load capacity of 200 pounds as a free standing unit or 600 pounds if unit is securely anchored.)

Removable, side-mounted water modifier/conditioner, with standard garden hose connection, processes water
through a specially designed 5 micron sediment filter, hydro-magnetic softener and de-ionization system and finally
an instantaneous heater to provide technician a constant source of pure, softened, modified de-ionized hot water.

Conditioned water and cleaning solutions are applied using a hand-held, medium-pressure cleaning gun with a narrow
10"long tube/nozzle to access hard to reach places.

Built-in air gun allows the technician a convenient means to remove surface contaminants before cleaning, as well
as removing excess moisture from cleaned equipment prior to drying.

Recessed lighting provides safe, well-lit working area.

Exhaust blower ventilation system with replaceable filter, reduces vapor mist in cleaning chamber, while lowering emissions in exhausted air.

Electronic switching valves enable technician to instantly change modes of operation from cleaning to rinsing to filling solution tank.

Cabinet construction is rugged powder-coated steel.

Bottom of cleaning chamber and top of turntable are coated with a mold/mildew resistant, rustproof material.

Coating of turntable helps to minimize scratching equipment during the cleaning process.

Conveniently located drain (with removable, powder-coated strainer) is designed to connect to standard garden hose.

Four heavy-duty casters (two being lockable) provide mobility for staging equipment where needed.

Cleaning system is designed to fit through a standard 36" doorway for on or off site cleaning.

Cleaning chamber is mounted on a powder-coated steel, key lockable storage cabinet ideal for securing supplies and tools.

**BUYER RESPONSIBLE FOR VERIFYING SPECIFICATIONS & OPTIONS**
